NocPix Omni H35R Multi Spectral Thermal Binoculars

The NocPix Omni H35R is a new generation pair of multispectral thermal binoculars combining high-resolution thermal imaging, digital day and night vision, infrared illumination and a built-in laser rangefinder in one compact binocular system. Designed for observation in changing light conditions, the H35R provides separate thermal and digital imaging channels, making it a versatile choice for users looking for thermal binoculars in the UK, thermal imaging binoculars, multispectral binoculars and a new day and night thermal binocular.

With a 640 × 512 thermal sensor, an 8192 × 6144 digital sensor, 50 Hz operation on both imaging channels and a 1600 × 1200 AMOLED display, the Omni H35R provides detailed viewing across thermal, daylight, dusk and night conditions. The digital channel can also be used with the supplied removable 850 nm IR illuminator, with support for an interchangeable 940 nm illuminator for digital night vision.

640 × 512 Thermal Imaging

At the heart of the Omni H35R is a 640 × 512 thermal detector with a 12 μm pixel pitch and NETD of ≤15 mK. The thermal channel uses a fast 35 mm F0.9 objective lens, giving a 2× base magnification that can be increased electronically up to 16×.

The thermal field of view is 12.5° × 9.4°, equivalent to 21.9 × 16.5 m at 100 m, providing a useful area for scanning, locating and following heat signatures.

The stated thermal detection range is up to 1800 m for a 1.7 × 0.5 m target at P(n)=99%. This is a detection specification and should not be treated as an identification distance.

The H35R also includes selectable thermal colour palettes, Ultra-clear mode, picture-in-picture viewing and electronic image stabilisation. Automatic and manual calibration, shutter and background calibration and pixel defect correction are available to help maintain a clear thermal image.

8K Digital Day and Night Vision

Alongside the thermal channel, the Omni H35R features an 8192 × 6144 digital sensor with a 1.2 μm pixel pitch and a 50 mm F1.8 digital objective lens.

This high-resolution digital channel provides 3× to 18× magnification and supports day, dusk and night viewing modes. It can produce colour images down to 0.001 lux and features a 140 dB dynamic range, helping retain visible detail as lighting conditions change.

For anyone looking for 8K multispectral binoculars, digital night vision binoculars, day and night binoculars or a new UK day and night thermal binocular, the combination of high-resolution digital imaging and thermal imaging makes the Omni H35R particularly versatile for observation.

The digital channel has a field of view of 8.8° × 6.6°, equivalent to 15.4 × 11.5 m at 100 m. Exposure and saturation can be adjusted independently to suit the viewing conditions.

Removable IR Illuminator

The H35R is supplied with a removable 850 nm infrared illuminator featuring low, medium and high output settings. This provides additional infrared illumination when using the digital night vision channel.

The binocular is also compatible with interchangeable 850 nm and 940 nm IR illuminators, giving users flexibility when setting up the digital night viewing system. Imaging settings for the individual channels are retained when switching between thermal and digital views.

Built-In 1000 m Laser Rangefinder

A Class 1 laser rangefinder is built into the NocPix Omni H35R, providing distance measurements up to 1000 metres directly through the viewing interface.

The rangefinder offers single measurement and continuous ranging modes. Continuous ranging can update the distance over a selected period or remain active continuously.

The H35R also supports ballistic calculation, allowing distance and ballistic reference information to be available while viewing through the binocular.

AMOLED Display and Comfortable Viewing

Images are displayed through a 0.5-inch 1600 × 1200 AMOLED display. The eyepieces provide 25 mm eye relief, a 12 mm exit pupil and individual -4 to +4 D dioptre adjustment.

The eyepiece spacing can also be adjusted for comfortable viewing. Separate thermal and digital focus wheels allow the active imaging channel to be focused directly, while a central zoom ring controls magnification.

The four-button control layout keeps the main functions accessible, while selected buttons can also be customised through the NocPix app.

Photo, Video and 64 GB Storage

The NocPix Omni H35R can record both photographs and video, with 64 GB of internal storage for saving footage directly on the binocular.

Photos are saved in JPEG format and video in MP4 format. A built-in microphone allows optional sound recording, while the onboard gallery makes it possible to review stored images and video without transferring them to another device.

Wi-Fi, NocPix App and N-Link

Built-in Wi-Fi allows the Omni H35R to connect with the NocPix app for live viewing and remote control. Bluetooth-assisted app connectivity is also supported.

The H35R features N-Link image and range data sharing, allowing compatible devices to share imaging and range information.

Dual Battery System

Power is supplied by a built-in battery together with two replaceable 18650 batteries. The removable cells can be inserted in either polarity orientation, making the system practical for field use.

Maximum operating time is stated at up to 7.5 hours at 22°C, although actual battery life will depend on how features such as Wi-Fi, recording and IR illumination are used.

The binocular accepts 5 V USB-C external power, with the internal battery rechargeable through the device. The removable 18650 batteries require a separate charger.

Built for Outdoor Use

The Omni H35R uses a magnesium-alloy housing with PVC grip surfaces and has an IP67 rating for protection against dust and water ingress.

A 1/4-20 UNC tripod connection is provided for users who want to mount the binoculars for stationary observation.

The operating temperature range is -20°C to +50°C, while the unit weighs less than 900 g without batteries and measures less than 198 × 144 × 75 mm.

Whether you are looking for a new thermal binocular, new UK thermal binocular, new day and night thermal binocular, multispectral binoculars, thermal imaging binoculars, digital night vision binoculars or high-resolution day and night binoculars, the NocPix Omni H35R combines thermal and digital imaging into a single observation system.

Key Features

• NocPix Omni H35R multispectral thermal binoculars
• Thermal and digital day/night imaging
• 640 × 512 thermal detector
• 12 μm thermal pixel pitch
• NETD ≤15 mK
• 35 mm F0.9 thermal objective
• Thermal magnification: 2×–16×
• Thermal detection range up to 1800 m*
• 8192 × 6144 digital sensor
• 1.2 μm digital pixel pitch
• 50 mm F1.8 digital objective
• Digital magnification: 3×–18×
• Digital colour imaging down to 0.001 lux
• 140 dB dynamic range
• Digital detection range up to 1000 m*
• 50 Hz thermal and digital frame rate
• 1600 × 1200 0.5-inch AMOLED display
• 25 mm eye relief
• 12 mm exit pupil
• -4 to +4 D dioptre adjustment
• Electronic image stabilisation
• Picture-in-picture function
• Selectable thermal palettes
• Ultra-clear mode
• Automatic and manual calibration
• Shutter and background calibration
• Pixel defect correction
• Built-in Class 1 laser rangefinder
• Rangefinder distance up to 1000 m
• Single and continuous ranging
• Ballistic calculation support
• Removable 850 nm IR illuminator included
• Low, medium and high IR output
• Compatible with 940 nm IR illuminator
• 64 GB internal storage
• JPEG photo and MP4 video recording
• Built-in microphone
• Onboard gallery
• Wi-Fi connectivity
• NocPix app support
• Bluetooth-assisted app connection
• N-Link image and range data sharing
• Four-button control system
• Customisable selected buttons through the app
• Built-in battery plus two replaceable 18650 batteries
• Up to 7.5 hours operation at 22°C*
• USB-C 5 V external power
• Magnesium-alloy housing
• PVC grip surfaces
• IP67 protection
• 1/4-20 UNC tripod connection
• Operating temperature: -20°C to +50°C
• Weight: <900 g without batteries
• Dimensions: <198 × 144 × 75 mm*Detection figures and operating time are manufacturer specifications and can vary according to conditions, settings and feature usage.
